AF-Edge

A VERSATILE FOOTING THAT CAN TAKE THE MOST HARD-TO-REACH PLACES AND GUARANTEE A GOOD INSTALLATION.

The location and angle of the piles makes this footing a great option for installations where footings are required in boundaries or near services.

STANDARD LOADINGS

• Up to 100 kN in Gravity*
• Up to 90 kN in Uplift*
• Up to 5kN.m in Bending Moments*
• Up to 35kN in lateral loading*

* Loadings subject to soil characteristics and capacities. Please consult your engineer to see what loads apply to your footing.

WE CAN MANUFACTURE CUSTOM ASSEMBLIES AND PARTS. ASK OUR SALES TEAM ABOUT DESIGN OPTIONS.
